HDPE Electro Fusion Tape Fittings for Pre-Insulated Pipeline Joint
Qingdao Huashida Machinery Co., Ltd.- Standard：DIN
- Material：Plastic
- Connection：Welding
- Surface Treatment：Chrome
- Head Type：Round
- Application：HDPE Pipeline Joint Closure
Base Info
- Model NO.：HSD
- Color：Black
- Thickness：3-15mm
- Width：Negotiable
- Transport Package：Standard Package
- Specification：EN253,EN448,EN728,ISO1133,ISO8501-1.ISO9001
- Trademark：HSD
- Origin：Qingdao, China
- HS Code：3921909090
- Production Capacity：2000sets,Day
Description
SpecificationSteel pipe outside diameter (mm) PE outside casing diameter (mm) Width(mm) Tic.mm DN159 285 600 4 DN219 315 600 4 DN273 365 600 4 DN325 420 600 5 DN377 500 600 5 DN426 550 600 6 DN478 630 600 6 DN529 655 600 6 DN630 760 600 8 DN720 850 600 8 DN820 960 600 10 DN920 1054 600 10 DN1020 1155 600 12 DN1220 1380 600 12 Technical Data: All of test according with the EN253-2003,ISO1183-2004,ISO6964-1986,EN728-1997 Final Test Unit Standard Test Result Result Raw material density g/cm 3 ≥0.935 ≤0.961 PASS Raw material melt flow rate g/10min ≤0.50 0.46 PASS Appearance check / Inernal and external surfaces is clean and free from other defects. Pass PASS Heat reversion % ≤3;shall not show any cracks 0.89,No cracks PASS Tensile yield strength Mpa ≥19 20.2 PASS Elongation at break % ≥350 656 PASS Stress crack resistance h ≥300 Pass PASS
Company Info
Qingdao Huashida Machinery Co., Ltd is a professional plastic extrusion production line manufacture since 2003. The factory covers 34000 square meter. Our products such as HDPE pressure pipe for gas or water transmission, structural wall pipe extrusion line, corrugated pipe extrusion line . The products have been exported to Middle East, Russia, Africa. Turkey, Korea.
Our factory locates in Cheng yang Industrial area, Qingdao ,Shandong Province. we have been approved and got certificate ISO90001:2008 by SGS. All the customers are welcome to visit the factory.
