• Model NO.：SUNWELL SW600
• Specification：Standard, Nonstandard, according your request
• Trademark：Sunwell
• Origin：Ningbo, China
• HS Code：848410000
• Production Capacity：4000000PCS,Month

Basic Info.

Model NO. SUNWELL SW600 Specification Standard, Nonstandard, according your request Trademark Sunwell Origin Ningbo, China HS Code 848410000 Production Capacity 4000000PCS/Month

Product Description

WRI SWG spiral wound gaskets(SUNWELL)
1.Products are manufactured in accordance with all relevant gasket standards.
2.All types of Spiral wound gaskets can be manufactured, CG, CGI, R, RIR, etc.
3.Our production capacity is 280,000 pcs per month.
4.Material combinations for all operating conditions.

WRI SWG spiral wound gasket is formed of V-shaped Metallic strip and soft non-metallic filler. Support rings, inside and Outside the spiral, improve the gasket's handing, fitting and Versatility.
Depend on its excellent compression resilience, it is suitable for sealing spots where the alteration of temperature and pressure are frequent.

SW600-CGI Inner & Outer Rings Type
A inner ring and outer ring type gasket will give an additional compression limiting stopper for gasket inner and outer side. It will prevent the corrosions on flange face at annular space. - Suitable for use with flat face and raised face flanges and specified for high pressure / temperature service - Class 900 and above or where corrosive or toxic media are present.

WRI SWG spiral wound gaskets Specifications
1.Products are manufactured in accordance with all relevant gasket standards to suit flange designations: ASME B 16.20, ASME B 16.5, BS1560, ASME B 16.47 A (B), BS EN 1092, DIN, JIS, and NF, etc.
2.Color cord as ASME B 16.20 on request.

More information of WRI SWG spiral wound gaskets,please contact with sunwell sealing co.
