304PTFE Spiral Wound Gaskets/Cgi Swg/Spw
Ningbo Sunwell Sealing Materials Co., Ltd.- Type：Flat Gasket
- Material：Ss304, 316L, Monel, CS, Graphite, PTFE...
- Color Code：According The Asme Standard
- Size：Asme B16.20,Asme B16.47ab,JIS,DIN,Nf
- Transport Package：Wooden Case
- Specification：Standard, Nonstandard, according your request
Base Info
- Model NO.：SUNWELL-SW600-20
- Trademark：Sunwell
- Origin：Ningbo, China
- Production Capacity：2800000PCS,Month
Description
Basic Info.
Model NO. SUNWELL-SW600-20 Trademark Sunwell Origin Ningbo, China Production Capacity 2800000PCS/MonthProduct Description
304PTFE spiral wound gaskets/CGI SWG/SPW1.Products are manufactured in accordance with all relevant gasket standards.
2.All types of Spiral wound gaskets can be manufactured, CG, CGI, R, RIR, etc.
3.Our production capacity is 150,000 pcs per month.
3.Material combinations for all operating conditions.
SUNWELL SW600 spiral wound gasket is formed of V-shaped Metallic strip and soft non-metallic filler. Support rings, inside and Outside the spiral, improve the gasket's handing, fitting and Versatility.
Depend on its excellent compression resilience, it is suitable for sealing spots where the alteration of temperature and pressure are frequent.
SW600-CGI Inner & Outer Rings Type
A inner ring and outer ring type gasket will give an additional compression limiting stopper for gasket inner and outer side. It will prevent the corrosions on flange face at annular space. - Suitable for use with flat face and raised face flanges and specified for high pressure / temperature service - Class 900 and above or where corrosive or toxic media are present.
More information of 304PTFE spiral wound gaskets/CGI SWG/SPW,please contact with sunwell sealing co.
