• Model NO.：KZBSS-PF
• Production Capacity：10000000

Basic Info.

Model NO. KZBSS-PF Production Capacity 10000000

Product Description

Features

1. Poppet valves available to prevent uncoupled leakage
2. Ball valves available for rugged dependability in heavy-duty hydraulic applications, within rated working pressure
3. Critical parts are induction hardened for durability
4. Dependable ball-locking mechanism holds the mating halves together
5. Socket and plug are precision machined from solid bar stock
6. KZE Series couplings interchange with couplings meeting ISO 7241-1, Series B.

Applications
This Series brings to the industry a proven sesing for use on construction equipment, forestry equipment, agricultural machinery, oil tools, steel mail machinery, and other demanding hydraulic applications.
.

Body size (in)	1/4 3/8 1/2 3/4 1
Rated Pressure (Bar)	350 300 300 250 200
Material:	Carbon steel
Standard seal material:	NBR (other material is available on request)
Temperature Range (Std seals):	-20°C to +80°C










Part No.	Thread size BSPP	A Overall Length (mm.)	B Exposed Length (mm.)	C Hex Size (mm.)	D Largest Diameter (mm.)	Part No.	Thread size NPT	A Overall Length (in.)	B Exposed Length (in.)	C Hex Size (in.)	D Largest Diameter (in.)
KZBSS-01PF	G1/8	41.0	10.0	14.0	17.0	KZBSS-N01PF	NPT1/8	1.61	0.41	0.56	0.65
KZBSS-02PF	G1/4	35.0	17.0	19.0	22.0	KZBSS-N02PF	NPT1/4	1.39	0.65	0.75	0.87
KZBSS-03PF	G3/8	38.0	14.0	22.0	26.0	KZBSS-N03PF	NPT3/8	1.50	0.54	0.88	1.01
KZBSS-04PF	G1/2	44.0	18.0	28.0	33.0	KZBSS-N04PF	NPT1/2	1.75	0.69	1.12	1.30
KZBSS-06PF	G3/4	55.0	20.0	35.0	40.0	KZBSS-N06PF	NPT3/4	2.16	0.79	1.38	1.59
KZBSS-08PF	G1	74.0	25.0	41.0	48.0	KZBSS-N08PF	NPT1	2.91	0.99	1.62	1.88
KZBSS-10PF	G1 1/4	76.0	25.0	54.0	59.0	KZBSS-N10PF	NPT1 1/4	2.99	0.99	2.13	2.32
KZBSS-12PF	G1 1/2	82.0	26.0	63.0	69.0	KZBSS-N12PF	NPT1 1/2	3.22	1.02	2.48	2.72
KZBSS-16PF	G2	88.0	28.0	77.0	84.0	KZBSS-N16PF	NPT2	3.46	1.10	3.03	3.30
