High Voltage Insulation Piercing Connector /Piercing Clamps10kv Series
Wenzhou Ziyong Electrical Co., Ltd.- Standard：GB, BS En
- Material：Plastic
- Connection：Flange
- Surface Treatment：Plated Copper
- Head Type：Round
- Body：UV-Resistance Plastic
Base Info
- Model NO.：JMA 10kV Series
- Bolt and Nuts：Stainless Steel
- Transport Package：100PCS,Carton or as Your Required
- Specification：IEC 60998-2-3
- Trademark：JMA
- Origin：China
- HS Code：8538900000
- Production Capacity：50000pcs,month
Description
CatalogConductors(mm²) Piercing depth Bolt Main Branch mm For main to main connection JMA10-240/240 95-240 95-240 4.5-6 2 For main to service connection JMA10-95/70 25-95 16-70 4.5-6 2 JMA10-185/50 95-185 16-50 4.5-6 2 JMA10-240/50 95-240 16-50 4.5-6 2 JMAF 10-95/25 25-95 GND 4.5-6 2 JMAF10-185/95 95-185 GND 4.5-6 2 JMAF10-240/150 95-240 GND 4.5-6 2
The waterproof insulation piercing connectors are suitable for majority types of ABC conductors as well as connections to service and lighting cable cores.
When tightening the bolts, the teeth of the contact plates penetrate the insulation and establish perfect contact. The bolts are tightened until the heads shear off.
Stripping of insulation is avoided.
Features
• Suitable for aluminium and copper conductors
• Shear head forces are adapted to the required contact forces for each application (main, service, lightning),
• Insulation material made of weather and UV resistant glass fiber reinforced polymer
• Contact plates made of aluminium or copper
• Conductor breaking loads are designed to exceed cable system requirements: 80% for self-supporting system 90 % for insulated neutral conductor and 60 % for phase conductors for system with insulated neutral messenger Standard
Service
Choose our products! You'll get
1) Good quality guarantee (2 years)
2) Factory direct prices
3) On time delivery
4) Free sample
5) Professional technology support
Strict quality controls have been taken to ensure that you'll get reliable products.
a. Material checks before production.
b. Random inspection during production.
c. Inspection before the shipment.
Our products fully comply with well recognized standards such as IEC, BS, ANSI.
FAQ:
1. Q: Do you have a catalog? Can you send me the catalog to have a check of all your products?
A: Yes, We have product catalog. Please contact us, we'll send our catalog by E-mail.
2 Q: I can't find the product on your catalog, can you make this product for me?
A: Our catalog shows most of our products but not all. If you couldn't find it, let us know the specification of your requirements, it usually takes 20-30 days for us to design and make new moulds which match your requirements.
3 Q: What's your payment term?
A: The price FOB Ningbo under payment term is 50% T/T in advance and the balance before shipment.
