- Model NO.：26791
- Sample：Available
- OEM：Acceptable
- MOQ：500 PCS
- Color：White or Yellow
- Delivery Time：25 Days for Normal Order
- Transport Package：Carton or as Request
- Specification：1,4"-2"
- Trademark：JJR
- Origin：Tianjin
- HS Code：7307990000
- Production Capacity：40000PCS,Day
| PART NO. | Thread E | HOSE BORE | DIMENSIONS |
| DN | DASH | A | C | H | S2 |
| 26791-04-03 | 7/16"X20 | 5 | 3 | 26.5 | 9 | 30.5 | 15 |
| 26791-04-04 | 7/16"X20 | 6 | 4 | 30 | 9 | 33.5 | 15 |
| 26791-05-04 | 1/2"X20 | 6 | 4 | 30 | 9.5 | 34 | 17 |
| 26791-05-05 | 1/2"X20 | 8 | 5 | 33 | 9.5 | 37 | 17 |
| 26791-05-06 | 1/2"X20 | 10 | 6 | 33 | 9.5 | 39 | 17 |
| 26791-06-04 | 9/16"X18 | 6 | 4 | 30 | 10.5 | 34 | 19 |
| 26791-06-05 | 9/16"X18 | 8 | 5 | 33 | 10.5 | 37 | 19 |
| 26791-06-06 | 9/16"X18 | 10 | 6 | 35 | 10.5 | 39 | 19 |
| 26791-06-08 | 9/16"X18 | 12 | 8 | 35 | 10.5 | 45 | 19 |
| 26791-08-06 | 3/4"X16 | 10 | 6 | 35 | 11 | 41 | 24 |
| 26791-08-08 | 3/4"X16 | 12 | 8 | 41 | 11 | 47 | 24 |
| 26791-08-10 | 3/4"X16 | 16 | 10 | 42 | 11 | 51 | 24 |
| 26791-10-08 | 7/8"X14 | 12 | 8 | 41 | 13 | 48 | 27 |
| 26791-10-10 | 7/8"X14 | 16 | 10 | 56 | 13 | 52 | 27 |
| 26791-10-12 | 7/8"X14 | 20 | 12 | 57 | 13 | 64 | 27 |
| 26791-12-08T | 1.1/16"X12 | 12 | 8 | 41 | 15 | 49 | 32 |
| 26791-12-10 | 1.1/16"X12 | 16 | 10 | 56 | 15 | 54 | 32 |
| 26791-12-12 | 1.1/16"X12 | 20 | 12 | 65 | 15 | 63 | 32 |
| 26791-12-16 | 1.1/16"X12 | 25 | 16 | 66 | 15 | 70 | 32 |
| 26791-14-12 | 1.3/16"X12 | 20 | 12 | 65 | 15 | 63 | 36 |
| 26791-16-12T | 1.5/16"X12 | 20 | 12 | 65 | 16 | 63 | 41 |
| 26791-16-16 | 1.5/16"X12 | 25 | 16 | 76 | 16 | 70 | 41 |
| 26791-16-20 | 1.5/16"X12 | 32 | 20 | 91 | 16 | 81 | 41 |
| 26791-20-20W | 1.5/8"X12 | 32 | 20 | 91 | 17 | 80 | 50 |
| 26791-24-20W | 1.7/8"X12 | 32 | 20 | 91 | 20 | 79 | 55 |
| 26791-24-24W | 1.7/8"X12 | 40 | 24 | 109 | 20 | 94 | 55 |
| 26791-32-32W | 2.1/2"X2 | 50 | 32 | 133 | 23.5 | 121 | 75 |
Swaged Metric FittingsMertic Flat Seal Fittings | | Metric Multiseal Fittings |
| Metric 60°Cone Seal Fittings |
| Metric 74°Cone Seal Fittings |
| Metric 24°Cone O-RING Seal L..T Fittings |
| Metric 24°Cone O-RING Seal H.T.Fittings |
| Metric Standpipe Straight Fittings |
| JIS Metric 60°Cone Seal Fitting |
| Swaged British Fittings | BSP O-RING Seal Fittings |
| BSP Flat Seal Fittings |
| BSP Multiseal Fittings |
| BSP 60°Cone Seal Fittings |
| BSPT Fittings |
| JIS BSP 60°Cone Seal Fittings |
| Swaged American Fittings | SAE O-RING Seal Fittings |
| ORFS Flat Seal Fittings |
| NPSM 60°Cone Seal Fittings |
| JIC 74°Cone Seal Fittings |
| NPT Fittings SAE Flange L.T. Fittiings |
| SAE Flange H.T.Fittings |
| Staplelok Fittings | Banjo Double connection |
| interlock Hose Fittings |
| Ferrule | FERRULE for SAE100R1AT/ EN 853 1SN HOSE |
| FERRULE for SAE100R1A EN 853 1ST HOSE |
| FERRULE for SAE100R2AT/DIN20022 2SN HOSE |
| FERRULE for SAE100R2A/EN 853 2SN HOSE |
| FERRULE for SAE100R1AT-R2AT,EN853 1SN-2SN and EN 857 2SC |
| FERRULE for 4SP,4SH/10-16,R12-06-16 HOSE |
| FERRULE for 4SH,R12/32 HOSE |
| Metric Adapters | Metric Thread O-RING Face Seal Adapters |
| Metric Thread Bite Type Tube Adapters |
| JIS Metric Thread 60°Cone Adapters |
| Metric Thread 74°Cone Flared Tube Adapters |
| British Adapters | BSP Thread 60°Cone Adapters |
| JIS BSP Thread 60°Cone Adapters |
| BSPT Thread Adapters |
| American Adapters | ORFS Adapters JIC 74°Cone Flared Tube Adapters |
| NPT Thread Adapters |
We carries a wide variety of hydraulic hose ferrule fittings in common size,used mainly for crimping hose fittings.More other type ferrule,fitting and hose please feel free to contact with us.
