ANSI 150lb Carbon Steel/Stainless Steel RF-Blind/Plate Flange
Hebei D&Z Pipe Fitting Mill Co., Ltd.- Standard：ANSI, DIN, GB, JIS, GOST
- Type：Welding Flange
- Material：Carbon Steel
- Structure：Flanges
- Connection：Welding
- Sealing Surface：RF
Base Info
- Model NO.：1,2"--72"
- Manufacturing Way：Forging
- Pressure：Class150 , Class300 , Class600
- Certification：ISO
- Surface Treatment：Anti-Rusting Oil , Black Painting
- Packing：Plywood Cases or Pallets
- Transport Package：Plywood Case or Pallets
- Specification：1,2"-72"
- Trademark：DZ
- Origin：China
- HS Code：73079100
- Production Capacity：800ton , Month
Description
NO.
FLANGE STANDARD
SIZE
PRESSURE RATING
TYPES
1
ANSI/ASME FLANGE B16.5
1/2"-24"
LBS: 150 300 400 600 900
1500 2500
SO.WN,SW,TH,LJ,BL
2
ORIFICE FLANGE B16.36
1"-24"
LBS: 300 400 600 900 1500 2500
SO,WN,TH
3
LONG WELDING NECK
FLANGES B16.5
1/2"-24"
LBS: 150 300 400 600 900 1500 2500
LWN
4
ASMEB16.47-A(MSS FLANGE)
26"-60"
LBS: 150 300 400 600 900
WN,BL
5
ASME B16.47-B(API FLANGE)
26"-60"
LBS: 75 150 300 400 600 900
WN,BL
6
AWWA C207 FLANGE
4"-120"
TABLE 2,3,4 CLASS B&D
SO,BL
7
API 590 FIG.8 FLANGE B16.48
1/2"-36"
LBS: 150 300 400 600 900 1500 2500
FIG.8
8
SPACER AND BLANK B16.48
1/2"-36"
LBS: 150 300 400 600
SPACER AND BLANK
9
BS 4504 FLANGE
DN10-2000
PN: 2.5 6 10 16 25 40
CODE: 101 111 112 113 105
10
SABS 1123 FLANGE
DN10-600
KPA: 600 1000 1600 2500 4000
SO.WN,SW,TH,LJ,BL
11
JIS B2220(KS B1503) FLANGE
DN10-1500
5K 10K 16K 20K 30K 40K
SO.WN,SW,TH,LJ,BL
12
GOST 12820/1-80
DN15-1200
PN: 1 1.6 2.5 4 6.3 10
SO,WN
13
AS 2129 FLANGE
DN15-1200
TABLE: D E F H
SO,BL
14
NS FLANGE
DN15-800
PN: 6 10 16 40
SO,BL
15
VSM FLANGE
DN15-200
PN: 6 10 16
SO,WN,BL
16
DIN FLANGE
DN10-4000
PN: 1 2.5 6 10 16 25 40 64 100
160 250 320 400
SO.WN,SW,TH,LJ,BL
17
EN1092 PL
DN10~DN600
PN6 PN10 PN16 PN25 PN40 PN63 PN100
TH SO WN BL
