• Model NO.：Filter Strainer
• Name：Water Strainer
• Origion：Tianjin
• Transport Package：Wooden Case or Carton
• Specification：CE, ROHS, SGS, GMP
• Trademark：U-ideal
• Origin：Tianjin, China
• HS Code：8421219990
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. Filter Strainer Name Water Strainer Origion Tianjin Transport Package Wooden Case or Carton Specification CE, ROHS, SGS, GMP Trademark U-ideal Origin Tianjin, China HS Code 8421219990 Production Capacity 50000PCS/Year

Product Description

Convenient to install, the strainer length is changable in 100mm, so make it more convenient to install. Safe installating time.

The strainer length extensionable Mainly used before the the release valve, control valves etc.

Y type draw rod extension strainer produced by our factory is made up of Y typestrainer and extension union joint.

YSTF draw rod expansion filter- Draw Rod Expansion Strainer has the same structure as Y- Type Strainer, but it is with an additional Expansion Joint on one end. The cleaning or working principle is the same as Y Type Strainer. However, there shall be kept easiness for expansion upon installation.

This Draw Rod Expansion Strainer is used as changing device for pressure relief valves, water valve or other major equipments or valves side to make mud buried belongings or installing or removing the valve head in order to maintain the normal use of the device.


Draw Rod Expansion Strainer main technical parameters:

Model	Nominal pressure PN(MPa)	Shell Test Pressure  (MPa)	Work pressure(MPa)
SY4P	1.0	1.5	1.0
YSTF	1.6	2.4	1.6



Name	Tube	Net	Draw rod expansion	O-ring
Material	Gray cast iron or ductile iron, steel, stainless steel	Stainless steel	Galvanized steel	NBR

Draw Rod Expansion Strainer Main dimensions:



DN(mm)	50	65	80	100	125	150	200	250	300
L	300	350	400	450	500	550	650	775	900
H	130	165	195	230	300	335	420	500	580
