- Model NO.：87311
- Sample：Available
- OEM：Acceptable
- MOQ：500 PCS
- Color：White or Yellow
- Delivery Time：25 Days for Normal Order
- Transport Package：Carton or as Request
- Specification：1,2"-2-1,2"
- Trademark：JJR
- Origin：Tianjin
- HS Code：7307990000
- Production Capacity：40000PCS,Day
| PART NO. | FLANGE SIZE | HOSE BORE | DIMENSIONS |
| DN | DASH | A | C | D | L |
| 87311-08-08 | 1/2" | 12 | 08 | 46 | 30.2 | 24 | 6.73 |
| 87311-12-08 | 3/4" | 12 | 08 | 47 | 38.1 | 31.7 | 6.73 |
| 87311-12-10 | 3/4" | 16 | 10 | 48 | 38.1 | 31.7 | 6.73 |
| 87311-12-12 | 3/4" | 20 | 12 | 48 | 38.1 | 31.7 | 6.73 |
| 87311-12-16 | 3/4" | 25 | 16 | 49 | 38.1 | 31.7 | 6.73 |
| 87311-16-12 | 1" | 20 | 12 | 51 | 44.4 | 38 | 8 |
| 87311-16-16 | 1" | 25 | 16 | 52 | 44.4 | 38 | 8 |
| 87311-16-20 | 1" | 32 | 20 | 53 | 44.4 | 38 | 8 |
| 87311-20-16 | 1.1/4" | 25 | 16 | 57 | 50.8 | 43 | 8 |
| 87311-20-20 | 1.1/4" | 32 | 20 | 58 | 50.8 | 43 | 8 |
| 87311-24-20 | 1.1/2" | 32 | 20 | 68 | 60.3 | 50 | 8 |
| 87311-24-24 | 1.1/2" | 40 | 24 | 68 | 60.3 | 50 | 8 |
| 87311-32-24 | 2" | 40 | 24 | 70 | 71.4 | 62 | 9.53 |
| 87311-32-32 | 2" | 50 | 32 | 70 | 71.4 | 62 | 9.53 |
| 87311-32-40 | 2" | 64 | 40 | 75 | 71.4 | 62 | 9.53 |
| 87311-40-32 | 2.1/2" | 50 | 32 | 73 | 84.1 | 74 | 9.53 |
| 87311-40-40 | 2.1/2" | 64 | 40 | 76 | 84.1 | 74 | 9.53 |
Swaged Metric FittingsMertic Flat Seal Fittings | | Metric Multiseal Fittings |
| Metric 60°Cone Seal Fittings |
| Metric 74°Cone Seal Fittings |
| Metric 24°Cone O-RING Seal L..T Fittings |
| Metric 24°Cone O-RING Seal H.T.Fittings |
| Metric Standpipe Straight Fittings |
| JIS Metric 60°Cone Seal Fitting |
| Swaged British Fittings | BSP O-RING Seal Fittings |
| BSP Flat Seal Fittings |
| BSP Multiseal Fittings |
| BSP 60°Cone Seal Fittings |
| BSPT Fittings |
| JIS BSP 60°Cone Seal Fittings |
| Swaged American Fittings | SAE O-RING Seal Fittings |
| ORFS Flat Seal Fittings |
| NPSM 60°Cone Seal Fittings |
| JIC 74°Cone Seal Fittings |
| NPT Fittings SAE Flange L.T. Fittiings |
| SAE Flange H.T.Fittings |
| Staplelok Fittings | Banjo Double connection |
| interlock Hose Fittings |
| Ferrule | FERRULE for SAE100R1AT/ EN 853 1SN HOSE |
| FERRULE for SAE100R1A EN 853 1ST HOSE |
| FERRULE for SAE100R2AT/DIN20022 2SN HOSE |
| FERRULE for SAE100R2A/EN 853 2SN HOSE |
| FERRULE for SAE100R1AT-R2AT,EN853 1SN-2SN and EN 857 2SC |
| FERRULE for 4SP,4SH/10-16,R12-06-16 HOSE |
| FERRULE for 4SH,R12/32 HOSE |
| Metric Adapters | Metric Thread O-RING Face Seal Adapters |
| Metric Thread Bite Type Tube Adapters |
| JIS Metric Thread 60°Cone Adapters |
| Metric Thread 74°Cone Flared Tube Adapters |
| British Adapters | BSP Thread 60°Cone Adapters |
| JIS BSP Thread 60°Cone Adapters |
| BSPT Thread Adapters |
| American Adapters | ORFS Adapters JIC 74°Cone Flared Tube Adapters |
| NPT Thread Adapters |
We carries a wide variety of hydraulic hose ferrule fittings in common size,used mainly for crimping hose fittings.More other type ferrule,fitting and hose please feel free to contact with us.
