• Model NO.：Saddle Clamps
• Specification：60mm -300mm
• Trademark：SOLID
• Origin：Shanxi, China
• Production Capacity：10000 Tons , Month

Basic Info.

Model NO. Saddle Clamps Specification 60mm -300mm Trademark SOLID Origin Shanxi, China Production Capacity 10000 Tons / Month

Product Description

Description

1. Material: Ductile Iron body
2. Gaskets :EPDM/NBR

3. Coating: epoxy in blue,black or red.

4. Size range: DN60-300mm

5. Packing: standard Wooden pallets or cases



Dimensions

DN(mm)	ΦDE	A	B	C	n-ΦD
60	64-85	166	140	95	4-Φ16
80	84-109	184	160	105	4-Φ18
100	108-125	195	160	98	4-Φ20
125	130-160	222	180	120	4-Φ20
150	159-184	240	205	108	4-Φ20
200	211-238	289	270	105	6-Φ20
250	251-283	326	360	140	6-Φ20
300	310-340	364	430	110	8-Φ20

FAQ

1. Can I get free samples?
A: Yes, we can provide you the free samples, but you need to bear their own delivery costs.

2. Can I request to change the form of packaging and transportation?
A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.

3. Can I request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.

4. Can I have my own Logo on the product?
A: Yes, you can send us your drawing and we can make your logo, but you have to bear their own the cost.

5. Can you produce the products according to my own drawings?
A: Yes, we can produce the products according to your drawings that will be most satisfy you.

6. Which price terms could accepted?
A: FOB,CIF all acceptable.
