• Model NO.：Expansion Joints
• Specification：DN20 - DN3000
• Trademark：SOLID
• Origin：Shanxi, China

Item

Specification

Operating condition

PN: 1.0/1.6/2.5 Mpa

The water temperature

up to 120ºC

Material

EPDM/NBR/NR body with Carbon steel flange

Size

DN20 - DN3000

Structure

Single Sphere, Double Sphere or more

Standard of Flange

BS, DIN, ANSI, JIS or others provided drawing samples

Media

Hot Air, SO2, Steam, Water, Oil, Acid,
Gas And etc.

Threads

DIN, BSPT, BSP, NPS, NPT, Metric,
(ISO7/1, DIN 2999, ANSI B1.20.1)

Surface

Galvanized, Epoxy

Application:

The joint could primarily reduce the quiver and the noise of the piping system; completely solve the different piping problems as displacement of joint, axial flex and etc.

Features: Improve the flow circulation and avoid the bellow deformation. Absorbs thermal expansion and shock. Structure: bellows + flat welding flanges. Main material: Compensates converting misalignment Bellows: stainless steel 304. Flanges: stainless steel 304 or carbon steel. Compensates for exhaust converter misalignment

Packing:
Carton + pallet.






FAQ

1. Can I get free samples?
A: Yes, we can provide you the free samples, but you need to bear their own delivery costs.

2. Can I request to change the form of packaging and transportation?
A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.

3. Can I request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.

4. Can I have my own Logo on the product?
A: Yes, you can send us your drawing and we can make your logo, but you have to bear their own the cost.

5. Can you produce the products according to my own drawings?
A: Yes, we can produce the products according to your drawings that will be most satisfy you.

6. Which price terms could accepted?
A: FOB,CIF all acceptable.
