DIN7337 High Strength Aluminium Stainless Steel Open Typewaterproof Multi Grip Pop Rivet/ Dome Head Blind Rivet
Jiaxing Haina Fastener Co., Limited- Surface Finishing：Plain
- Certification：ISO
Base Info
- Model NO.：DIN7337
- Performance：Eco-Friendly
- Customized：Customized
- Available Material：Aluminum (5050,5154), Steel, Stainless Steel
- Surface Finish：Zinc Plated
- Head Type：Dome Head. Csk Head, Large Flange Head
- Class/Grade：3.6, 4.8, 5.6, 6.8, 8.8, 9.8, 10.9, 12.9
- Orgin：China
- Size：Customized
- Diameter：3.2mm, 4.0mm, 4.8mm, 5mm, 6mm, (1,8, 5,32, 3,16)
- Transport Package：20-25kg Carton+900kg,Pallet
- Specification：ISO9001: 2008
- Trademark：HN
- Origin：China
- HS Code：731815
- Production Capacity：500ton,Month
Description
DIN7337B,Blind RivetDia. D 3 3.2 4 4.8 5 6 6.4 Max 3.08 3.28 4.08 4.88 5.08 6.08 6.48 Min 2.9 3.1 3.85 4.65 4.85 5.85 6.25 Rod diameter Max 6 6 7.5 9 9 11 12 Min 5.6 5.6 7 8.5 8.5 10.3 11.3
1. Materials: Aluminum (5050,5154)/ steel/ stainless steel
2. Finish: Baking vanish,Zinc plating, nickel plating, Dacromet
3. Head type: Dome head. CSK head, large flange head,
4. Diameter: 3.2mm, 4.0mm, 4.8mm, 5mm,6mm, (1/8, 5/32, 3/16,1/4)
5. Length: 5mm - 35mm
1. Materials: Aluminum (5050,5154)/ steel/ stainless steel
2. Finish: Baking vanish,Zinc plating, nickel plating, Dacromet
3. Head type: Dome head. CSK head, large flange head,
4. Diameter: 3.2mm, 4.0mm, 4.8mm, 5mm,6mm, (1/8, 5/32, 3/16,1/4)
5. Length: 5mm - 35mm
