• Model NO.：KZE-SF
• Trademark：SMT
• Origin：China
• Production Capacity：10000000

Basic Info.

Model NO. KZE-SF Trademark SMT Origin China Production Capacity 10000000

Product Description

Features

1. Poppet valves available to prevent uncoupled leakage
2. Ball valves available for rugged dependability in heavy-duty hydraulic applications, within rated working pressure
3. Critical parts are induction hardened for durability
4. Dependable ball-locking mechanism holds the mating halves together
5. Socket and plug are precision machined from solid bar stock
6. KZE Series couplings interchange with couplings meeting ISO 7241-1, Series A.

Applications
This Series brings to the industry a proven sesing for use on construction equipment, forestry equipment, agricultural machinery, oil tools, steel mail machinery, and other demanding hydraulic applications.

Body size (in)	1/4 3/8 1/2 3/4 1
Rated Pressure (Bar)	350 300 300 250 200
Material:	Carbon steel
Standard seal material:	NBR (other material is available on request)
Temperature Range (Std seals):	-20°C to +80°C










Part No.	Thread size BSPP	E Overall Length (mm.)	F Hex Size (mm.)	G Largest Diameter (mm.)	Part No.	Thread size NPT	E Overall Length (in.)	F Hex Size (in.)	G Largest Diameter (in.)
KZE-01SF	G1/8	47.0	22.0	27.0	KZE-N01SF	NPT1/8	1.85	0.88	1.08
KZE-02SF	G1/4	47.0	22.0	27.0	KZE-N02SF	NPT1/4	1.85	0.88	1.08
KZE-03SF	G3/8	55.0	27.0	32.0	KZE-N03SF	NPT3/8	2.18	1.06	1.27
KZE-04SF	G1/2	70.0	32.0	39.0	KZE-N04SF	NPT1/2	2.75	1.25	1.52
KZE-06SF	G3/4	85.0	41.0	48.0	KZE-N06SF	NPT3/4	3.38	1.62	1.90
KZE-08SF	G1	104.0	48.0	54.0	KZE-N08SF	NPT1	4.11	1.88	2.14
KZE-10SF	G1 1/4	110.0	54.0	69.0	KZE-N10SF	NPT1 1/4	4.33	2.12	2.71
KZE-12SF	G1 1/2	128.0	60.0	82.0	KZE-N12SF	NPT1 1/2	5.03	2.36	3.22
KZE-16SF	G2	153.0	77.0	100.0	KZE-N16SF	NPT2	6.02	3.03	3.93
