Torx/Star Drive Pocket Hole Screws for Cabinetry, Furniture, etc - T-20 Torx Screw Head
Younsion Fastening Industrial Co., Ltd.- Material：Iron
- Shape of Head：Round
- Shape of Groove：Torx
- Surface Finishing：Gold Plated
- Certification：ISO, GS, RoHS, CE
- Customized：Customized
Base Info
- Model NO.：SWS02
- Transport Package：Boxes, Carton with Pallet
- Specification：M3.5-M10
- Trademark：YS
- HS Code：7318140090
- Production Capacity：1296tons,Years
Description
Basic Info.
Model NO. SWS02 Transport Package Boxes, Carton with Pallet Specification M3.5-M10 Trademark YS HS Code 7318140090 Production Capacity 1296tons/YearsProduct Description
| Dimension | Small packing | Large packing | Weight |
| (mm) | (pcs.) | (pcs.) | (kg/100 pc) |
| 2,5x10 | 1 000 | --- | 0,05 |
| 2,5x12 | 1 000 | --- | 0,06 |
| 2,5x16 | 1 000 | --- | 0,1 |
| 2,5x20 | 1 000 | --- | 0,11 |
| 2,5x25 | 1 000 | --- | 0,13 |
| 2,5x30 | 1 000 | --- | 0,14 |
| 3x10 | 1 000 | --- | 0,05 |
| 3x12 | 1 000 | --- | 0,06 |
| 3x16 | 1 000 | 45 000 | 0,06 |
| 3x20 | 1 000 | 27 000 | 0,07 |
| 3x25 | 1 000 | 17 000 | 0,08 |
| 3x30 | 1 000 | 17 000 | 0,1 |
| 3x35 | 1 000 | 17 000 | 0,11 |
| 3x40 | 1 000 | 12 000 | 0,13 |
| 3x45 | 1 000 | 10 000 | 0,14 |
| 3x50 | 1 000 | 9 000 | 0,14 |
| 3,5x16 | 1 000 | 27 000 | 0,07 |
| 3,5x20 | 1 000 | 18 000 | 0,09 |
| 3,5x25 | 1 000 | 17 000 | 0,11 |
| 3,5x30 | 1 000 | 14 000 | 0,12 |
| 3,5x35 | 1 000 | 14 000 | 0,14 |
| 3,5x40 | 1 000 | 12 000 | 0,16 |
| 3,5x45 | 1 000 | 9 000 | 0,18 |
| 3,5x50 | 1 000 | 9 000 | 0,2 |
| 3,5x55 | 1 000 | 6 000 | 0,21 |
| 3,5x60 | 1 000 | 6 000 | 0,22 |
| 4x12 | 500 | --- | 0,09 |
| 4x16 | 1 000 | 25 000 | 0,1 |
| 4x20 | 1 000 | 20 000 | 0,12 |
| 4x25 | 1 000 | 14 000 | 0,15 |
| 4x30 | 1 000 | 12 000 | 0,17 |
| 4x35 | 500 | 8 500 | 0,19 |
| 4x40 | 500 | 7 000 | 0,21 |
| 4x45 | 500 | 7 000 | 0,23 |
| 4x50 | 500 | 6 000 | 0,26 |
| 4x55 | 500 | 5 000 | 0,29 |
| 4x60 | 500 | 4 500 | 0,32 |
| 4x70 | 250 | 3 500 | 0,37 |
| 4x80 | 250 | 3 500 | 0,42 |
| 4,5x16 | 1 000 | 18 000 | 0,12 |
| 4,5x20 | 1 000 | 14 000 | 0,13 |
| 4,5x25 | 1 000 | 14 000 | 0,17 |
| 4,5x30 | 1 000 | 12 000 | 0,21 |
| 4,5x35 | 1 000 | 9 000 | 0,25 |
| 4,5x40 | 500 | 7 000 | 0,28 |
| 4,5x45 | 500 | 6 000 | 0,31 |
| 4,5x50 | 500 | 5 000 | 0,35 |
| 4,5x55 | 500 | 5 000 | 0,39 |
| 4,5x60 | 500 | 4 500 | 0,44 |
| 4,5x70 | 250 | 3 500 | 0,48 |
| 4,5x80 | 250 | 3 500 | 0,53 |
| 5x16 | 500 | --- | 0,172 |
| 5x20 | 1 000 | 12 000 | 0,22 |
| 5x25 | 1 000 | 10 000 | 0,25 |
| 5x30 | 1 000 | 9 000 | 0,28 |
| 5x35 | 1 000 | 8 000 | 0,32 |
| 5x40 | 500 | 7 000 | 0,36 |
| 5x45 | 500 | 6 000 | 0,4 |
| 5x50 | 500 | 5 000 | 0,43 |
| 5x55 | 500 | 5 000 | 0,47 |
| 5x60 | 250 | 4 250 | 0,51 |
| 5x70 | 250 | 3 500 | 0,58 |
| 5x80 | 250 | 3 500 | 0,66 |
| 6x25 | 200 | --- | 0,4 |
| 6x30 | 500 | 5 000 | 0,44 |
| 6x35 | 500 | 4 500 | 0,5 |
| 6x40 | 250 | 3 500 | 0,56 |
| 6x45 | 250 | 3 500 | 0,61 |
| 6x50 | 250 | 3 500 | 0,67 |
| 6x55 | 250 | 3 000 | 0,71 |
| 6x60 | 250 | 2 500 | 0,75 |
| 6x70 | 250 | 2 250 | 0,89 |
| 6x80 | 250 | 2 250 | 0,99 |
Specification for Half Thread Chipboard Screws
| Dimension | Small packing | Large packing | Weight |
| (mm) | (pcs.) | (pcs.) | (kg/100 pc) |
| 3,5x25/18 | 1 000 | 27 000 | 0,11 |
| 3,5x30/18 | 1 000 | 17 000 | 0,12 |
| 3,5x35/21 | 1 000 | 14 000 | 0,14 |
| 3,5x40/25 | 1 000 | 12 000 | 0,16 |
| 3,5x45/28 | 1 000 | 9 000 | 0,18 |
| 3,5x50/30 | 500 | 6 000 | 0,20 |
| 3,5x55/36 | 1 000 | 6 000 | 0,21 |
| 3,5x60/36 | 1 000 | 6 000 | 0,22 |
| 4x30/18 | 1 000 | 14 000 | 0,17 |
| 4x35/24 | 500 | 8 500 | 0,19 |
| 4x40/24 | 500 | 7 000 | 0,21 |
| 4x45/30 | 500 | 7 000 | 0,23 |
| 4x50/30 | 500 | 6 000 | 0,26 |
| 4x55/36 | 500 | 5 000 | 0,29 |
| 4x60/36 | 500 | 4 500 | 0,32 |
| 4x70/42 | 250 | 3 500 | 0,37 |
| 4x80/50 | 250 | 3 500 | 0,42 |
| 4,5x40/24 | 500 | 7 000 | 0,28 |
| 4,5x45/30 | 500 | 6 000 | 0,31 |
| 4,5x50/30 | 500 | 4 500 | 0,35 |
| 4,5x55/36 | 500 | 4 500 | 0,39 |
| 4,5x60/36 | 500 | 4 500 | 0,44 |
| 4,5x70/42 | 250 | 3 000 | 0,48 |
| 4,5x80/50 | 250 | 2 500 | 0,53 |
| 4,5x90/60 | 250 | 2 250 | 0,58 |
| 5x40/24 | 500 | 7 000 | 0,36 |
| 5x45/30 | 500 | 6 000 | 0,40 |
| 5x50/30 | 500 | 4 500 | 0,43 |
| 5x55/36 | 500 | 4 500 | 0,47 |
| 5x60/36 | 250 | 3 000 | 0,51 |
| 5x70/42 | 250 | 2 500 | 0,58 |
| 5x80/50 | 250 | 2 250 | 0,66 |
| 5x90/60 | 200 | 1 800 | 0,74 |
| 5x100/60 | 200 | 1 200 | 0,80 |
| 5x110/70 | 200 | 1 200 | 0,97 |
| 5x120/70 | 200 | 1 800 | 1,06 |
| 6x60/36 | 250 | 2 500 | 0,75 |
| 6x70/42 | 250 | 2 250 | 0,89 |
| 6x80/50 | 250 | 2 250 | 0,99 |
| 6x90/60 | 250 | 2 250 | 1,08 |
| 6x100/60 | 250 | 1 500 | 1,17 |
| 6x110/70 | 200 | 1 200 | 1,24 |
| 6x120/70 | 200 | 1 800 | 1,37 |
| 6x140/70 | 200 | 1 800 | 1,63 |
| 6x150/70 | 100 | 900 | 1,74 |
| 6x160/70 | 100 | 900 | 1,85 |
| 6x180/70 | 100 | 600 | 2,22 |
| 6x200/70 | 100 | 600 | 2,43 |
| Dimension (mm) | Size of the hexalobular recess | Packing (pcs.) | Weight (kg/100pcs) |
| 8x80 | 40 | 50 | 1,80 |
| 8x90 | 40 | 50 | 2,00 |
| 8x100 | 40 | 50 | 2,20 |
| 8x120 | 40 | 50 | 2,60 |
| 8x140 | 40 | 50 | 3,00 |
| 8x160 | 40 | 50 | 3,40 |
| 8x180 | 40 | 50 | 3,80 |
| 8x200 | 40 | 50 | 4,20 |
| 8x220 | 40 | 50 | 4,60 |
| 8x240 | 40 | 50 | 5,00 |
| 8x260 | 40 | 50 | 5,40 |
| 8x280 | 40 | 50 | 5,80 |
| 8x300 | 40 | 50 | 6,20 |
| 8x320 | 40 | 50 | 6,70 |
| 8x340 | 40 | 50 | 7,20 |
| 8x360 | 40 | 50 | 7,60 |
| 8x380 | 40 | 50 | 8,00 |
| 8x400 | 40 | 50 | 8,48 |
