1500bar Self-Return Hydraulic Bolt Tensioner with Inner Thread (SV31LS series)
SOV Hydraulic Technology (Shanghai) Co., Ltd.- Material：High Strength Steel
- Type：Hydraulic Bolt Tensioner
- Connection：Common Bolt
- Head Style：Hexagonal
- Standard：DIN
- Grade：9.8
Base Info
- Model NO.：SV31LS series
- Thread Size：M22-M100
- Max Tensile Force：200-5830kn
- Stock：Yes
- OEM：Yes
- Payment：T,T
- Transport Package：Wooden Package
- Specification：CE ISO9001: 2008
- Trademark：SOV, Powerteam, Titan, Hytorc, Enerpac
- Origin：Shanghai
- Production Capacity：700PCS,Month
Description
ModelThread coupling Max tensile force Size M Inch KN A B C D E F SV31LS22 M22 7/8 200 42 52 65 19 20 94 SV31LS24 M24 1 290 49 60 78 22 24 102 SV31LS27 M27 1-1/8 380 55 67 86 25 27 108 SV31LS30 M30 1-1/8 460 61 74 97 27 30 106 SV31LS33 M33 1-1/4 570 66 81 107 29 33 114 SV31LS36 M36 1-3/8 670 71 90 117 32 36 118 SV31LS39 M39 1-1/2 800 77 96 127 34 39 125 SV31LS42 M42 1-5/8 920 83 102 137 37 42 134 SV31LS45 M45 1-3/4 1080 89 110 148 39 45 135 SV31LS48 M48 1-7/8 1220 94 116 158 42 48 140 SV31LS52 M52 2 1450 102 128 169 46 52 151 SV31LS56 M56 2-1/4 1680 106 135 176 49 56 158 SV31LS60 M60 2-3/8 2010 114 142 199 52 60 167 SV31LS64 M64 2-1/2 2210 120 151 211 55 64 172 SV31LS68 M68 2-3/4 2600 124 155 228 58 68 180 SV31LS72 M72 3-7/8 2880 130 168 238 62 72 186 SV31LS80 M80 3-1/4 3610 142 188 267 68 80 202 SV31LS90 M90 3-1/2 4650 160 210 300 77 90 220 SV31LS100 M100 4 5830 178 237 340 85 100 240
