Bsp Union Type Twin Sphere Rubber Expansion Joint
Shanxi Solid Industrial Co., Ltd.- Standard：DIN, ANSI
- Material：Stainless Steel
- Connection：Flange
- Surface Treatment：Galvanized Sheet
- Head Type：Round
- Transport Package：Cases or Pallets
Base Info
- Model NO.：Expansion Joint
- Specification：DN50-DN400
- Trademark：SOLID
- Origin：Shanxi, China
- Production Capacity：1000 Tons , Month
Description
| working pressureMPa(kgf/cm2 ) | 1.0(10) | deflection angle | (a1+a2 )45° | |
| burst pressureMPa(kgf/cm2 ) | 3.0(30) | vacuumeKPa(mm/Hg) | 53.3(400) | |
| applicable tempressure | -15~115`C(for special conditions)-30~250`C | |||
| applicable media | water,sea water,hot water,air,compressure,air oil,acid,alkali,etc. | |||
Main Connecting Dimension
| nominal diameter | length(mm) | axinal displacemant | horizontal displacement(mm) | ||
| mm | inch | extension | compression | ||
| 20 | 0.75 | 180 | 5~6 | 22 | 22 |
| 25 | 1 | 180 | 5~6 | 22 | 22 |
| 32 | 1.25 | 200 | 5~6 | 22 | 22 |
| 40 | 1.5 | 210 | 5~6 | 22 | 22 |
| 50 | 2 | 220 | 5~6 | 22 | 22 |
| 65 | 2.5 | 245 | 5~6 | 22 | 22 |
FAQ
1. Can I get free samples?
A: Yes, we can provide you the free samples, but you need to bear their own delivery costs.
2. Can I request to change the form of packaging and transportation?
A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
3. Can I request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.
4. Can I have my own Logo on the product?
A: Yes, you can send us your drawing and we can make your logo, but you have to bear their own the cost.
5. Can you produce the products according to my own drawings?
A: Yes, we can produce the products according to your drawings that will be most satisfy you.
6. Which price terms could accepted?
A: FOB,CIF all acceptable.
