Forged Loose Flange for Glass Lined Reactor
Zibo Dewojin Trading Co., Ltd.- Standard：GB
- Type：Loose Flange for Glass Lined Reactor
- Material：Carbon Steel
- Structure：Flanges
- Connection：Flanged
- Sealing Surface：FF
Base Info
- Manufacturing Way：Forging
- Trademark：DEWOJIN
- Origin：Zibo, China
- HS Code：8419
- Production Capacity：10000 Pieces,Year
Description
Norminal Capacity LActual Capacity L Jacket Heating Area m2 Reducer Specification of Packing Box
DN Specification of Drain Valve
DN AgitatorRotation Speed r/min Size(mm) Achor
Frame Impeller
Turbin
Paddle D D0 D1 D2 D3 D4 H H1 H2 H3 L h Weight
Kg Achor
Frame Impeller
Turbin
Paddle K50 70 0.59 BLD0.75-1 40 65 63/85 85/130 500 350 600 708 270 / 480 300 280 923 2060 50 90 365 K100 127 0.9 BLD0.75-1 40 65 63/85 85/130 600 420 700 826 270 / 580 350 315 923 2250 60 110 435 K200 241 1.5 BLD1.1-1 50 80 63/85 85/130 700 490 800 927 300 / 765 350 340 938 2470 60 130 580 K300 361 1.94 BLD3-2 65 80 63/85 85/130 800 560 900 1055 350 / 865 380 375 1098 2760 80 150 780 K500 579 2.71 BLD3-2 65 80 63/85 85/130 900 630 1000 1156 350 / 1065 400 400 1098 3020 80 150 945 K1000 1238 4.54 BLD4-3 80 100 63/85 85/130 1200 840 1300 1488 400 950 1275 500 480 1242 3430 100 210 1685 K1500 1714 5.38 BLD4-3 80 100 63/85 85/130 1300 910 1450 1639 400 1080 1470 600 505 1242 3660 100 210 1990 K2000 2152 7.2 BLD4-3 80 100 63/85 85/130 1300 910 1450 1639 400 1080 1810 600 505 1242 4010 100 210 2225 K3000 3200 8.9 BLD5.5-3 95 125 63/85 85/130 1600 1120 1750 1981 450 1300 1810 600 590 1302 4159 130 240 3190 K5000 5286 13.0 BLD7.5-4 95 125 63/85 85/130 1750 1200 1900 2131 450 1400 2428 700 628 1382 4840 130 270 4455 K6300 6248 15.2 BLD7.5-4 95 125 63/85 85/130 1750 1200 1900 2131 450 1400 2828 700 628 1382 5240 130 270 4950 K8000 8038 17.05 BLD11-5 110 125 63/85 85/130 2000 1400 2200 2502 455 1650 2800 780 700 1455 5000 150 300 6210 K10000 10200 22.6 BLD11-5 110 150 63/85 85/130 2200 1540 2400 2708 510 1800 2955 800 750 1495 5285 150 330 7680 F3000 3625 8.9 BLD5.5-3 95 125 / 85/130 1600 1120 1750 1981 600 1300 2255 1060 150 1302 4190 / 240 2910 F5000 5858 13.2 BLD7.5-3 95 125 / 85/130 1750 1200 1900 2131 600 1400 2911 1200 150 1302 4900 / 270 4100 F6300 6820 15.4 BLD7.5-4 95 125 / 85/130 1750 1200 1900 2131 600 1400 3311 1200 150 1382 5330 / 270 4595 F8000 9273 18.0 BLD11-5 95 125 / 85/130 2000 1400 2200 2502 800 1650 3465 1350 180 1455 5510 / 330 6235 F10000 11443 20.5 BLD11-5 110 150 / 85/130 2200 1540 2400 2708 800 1800 3570 1450 180 1495 5690 / 360 7845 F12500 13640 24.5 BLD11-5 110 150 / 85/130 2200 1540 2400 2708 800 1800 4145 1450 180 1495 6450 / 360 8920 F16000 17446 29.5 BLD18.5-6 130 150 / 85/130 2400 1680 2600 2912 800 1950 4440 1450 180 2180 7220 / 360 11350 F20000 21750 34.4 BLD18.5-6 130 150 / 85/130 2600 1820 2800 3182 900 2100 4700 1450 230 2180 7710 / 400 13545 F30000 32520 42.7 BLD22-7 140 150 / 85/130 3000 2100 3200 3788 1100 2400 5240 1600 280 2200 7620 / 450 19860
