Power-Seal Worm-Drive Stainless Steel 2-PCS Housing Perforated Heavy Duty Hose Clamp for Automotive Systems, 117-140mm
Tianjin City Kainuo Industrial Company Limited
- Standard：DIN, GB
- Material：Stainless Steel
- Connection：Hose Clip
- Surface Treatment：Galvanized Sheet
- Head Type：Round
- Product Name：American Type Hose Clamp
- Model NO.：MS05D80
- Type：Heavy Duty Hose Clamp
- Scope of Application：Auto Parts
- Certification：ISO,TUV,BSCI,IATF
- Transport Package：Plastic Bag Carton
- Specification：117-140mm
- Trademark：TJBC
- Origin：Tianjin
- HS Code：732690
- Production Capacity：10000 PCS,Day
| 14.2mm(bandwidth 14.2mm) | | SAE no | mm | inch | W2 | W4 | W1 | W4 |
| 6 | 11-20 | 0.44"-0.78" | MS05B6 | MS05D6 | | |
| 8 | 13-23 | 0.5"-0.91" | MS05B8 | MS05D8 | | |
| 10 | 14-27 | 0.56"-1.06" | MS05B10 | MS05D10 | | MS06D10 |
| 12 | 18-32 | 0.69"-1.25" | MS05B12 | MS05D12 | | MS06D12 |
| 16 | 21-38 | 0.81"-1.5" | MS05B16 | MS05D16 | MS06A16 | MS06D16 |
| 20 | 21-44 | 0.81"-1.75" | MS05B20 | MS05D20 | MS06A20 | MS06D20 |
| 24 | 27-51 | 1.06"-2" | MS05B24 | MS05D24 | MS06A24 | MS06D24 |
| 28 | 33-57 | 1.31"-2.25" | MS05B28 | MS05D28 | MS06A28 | MS06D28 |
| 32 | 40-64 | 1.56"-2.5" | MS05B32 | MS05D32 | MS06A32 | MS06D32 |
| 36 | 46-70 | 1.81"-2.75" | MS05B36 | MS05D36 | MS06A36 | MS06D36 |
| 40 | 50-76 | 2.06"-3" | MS05B40 | MS05D40 | MS06A40 | MS06D40 |
| 44 | 59-83 | 2.31"-3.25" | MS05B44 | MS05D44 | MS06A44 | MS06D44 |
| 48 | 65-89 | 2.56"-3.5" | MS05B48 | MS05D48 | MS06A48 | MS06D48 |
| 52 | 72-95 | 2.81"-3.75 | MS05B52 | MS05D52 | MS06A52 | MS06D52 |
| 56 | 78-102 | 3.06"-4" | MS05B56 | MS05D56 | MS06A56 | MS06D56 |
| 60 | 84-108 | 3.31"-4.25" | MS05B60 | MS05D60 | MS06A60 | MS06D60 |
| 64 | 91-114 | 3.56"-4.5" | MS05B64 | MS05D64 | MS06A64 | MS06D64 |
| 72 | 103-127 | 4.06"-5" | MS05B72 | MS05D72 | MS06A72 | MS06D72 |
| 80 | 117-140 | 4.62"-5.5" | MS05B80 | MS05D80 | MS06A80 | MS06D80 |
| 88 | 130-152 | 5.12"-6" | MS05B88 | MS05D88 | MS06A88 | MS06D88 |
| 96 | 141-165 | 5.56"-6.5" | MS05B96 | MS05D96 | MS06A96 | MS06D96 |
| 104 | 157-178 | 6.18"-7" | MS05B104 | MS05D104 | MS06A104 | MS06D104 |
MS05 5.3Nm
MS06 7.5Nm
MS08 11Nm| W2 | AISI 301SS | AISI 301SS | Zinc plated steel |
| W4 | AISI 304SS | AISI 304SS | AISI 304SS |
