EPDM Rubber Flexible Expansion Galvanized Pipe Coupling
TAIZHOU EASTAR TECHNOLOGY CO., LTD.- Standard:DIN, ANSI, GB, JIS, BSW
- Material:Ductile Iron
- Connection:Flange
- Surface Treatment:Galvanized Sheet
- Head Type:Round
- Medium:Sea Water,Oil,Gas,Acid,Alkali
Base Info
- Model NO.:REJ07
- Delivery Time:20~40 Days, Depend on The Quantity
- Color:Black, Green, Gray, Silver.
- Flange Materila:Ci,Di,Wcb,Alb,CF8,CF8m
- Connect Type:Flange, Thread
- Environmental Test:Lead Free
- Export Markets:Global
- Rubber Material:NBR,Cr,EPDM,Iir
- Transport Package:Box&Crate, Standard Export Packaging
- Specification:Dn15 -Dn80
- Trademark:XINBO ,OEM
- Origin:Zhejiang China
- HS Code:7307990000
- Production Capacity:50000PCS,Year
Description
Nominal diameter(mm)20~80 20~80 Nominal pressure(Mpa) 1.0 1.6 Testing pressure Seal(Mpa) 1.1 1.76 Explosion pressure(Mpa) 4.8 Suitable temperature(°C) -15°C~110°C Suitable medium Air,compressed air,water,seawater,hotwater,oil and acid Threaded Connector Malleable Cast Iron Key frame Nylon Cord Fabric Inner/Outer Rubber EPDM/NBR/NR Pressurised ring Steel wire Length(mm)
Axial Displacement DN INCH Extrnsion Compression 20 3/4 200 5~6 22 22 45° 0.9 25 1 200 5~6 22 22 45° 1.15 32 1.25 200 5~6 22 22 45° 1.4 40 1.5 200 5~6 22 22 45° 1.65 50 2 200 5~6 22 22 45° 2.25 65 2.5 265 8~10 24 24 45° 3.25 80 3 285 8~10 24 24 45° 4.2
Why Choose US
We test leakage of each roll before braiding, then we cut 300mm and crimp it to test
burst pressure after brading.
We use CNC Lathes Machine for end fittings production. Machine system, knife and inspection
tools are all imported from Japan.
We use Techmaflex Crimping Machine which is imported from France. This machine has
accurate and stable performance for crimping because it is produced for PTFE hose crimping only.
Contact to this supplier
Overall Dimension and Weight
Size
Axial Displacement
Horizontal
displacement (mm)
Deflexion
angle
Weight
(kg)
