• Model NO.：TF
• Heating Model：Steam,Hot Oil,Hot Water,Electrical
• Function：Transport Liquid
• Key Selling Points：Energy-Saving ,High Effective , Vacuum ,Evaporator
• Keywords：Sight Glass,Sight Light,Vent Filter,Spray Ball,Ma
• Applicable Industries：Dairy Products, Beer, Food, Beverage, Pharmaceutic
• Transport Package：Export Standard Package
• Trademark：JOSTON
• Origin：Wenzhou
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. TF Heating Model Steam/Hot Oil/Hot Water/Electrical Function Transport Liquid Key Selling Points Energy-Saving /High Effective / Vacuum /Evaporator Keywords Sight Glass/Sight Light//Vent Filter/Spray Ball/Ma Applicable Industries Dairy Products, Beer, Food, Beverage, Pharmaceutic Transport Package Export Standard Package Trademark JOSTON Origin Wenzhou Production Capacity 30 Sets/Month

Product Description

Tank Fittings Sight Glass Sight Light Vent Filter Spray Ball Manhole
tank fittings all adopt the aspetic design ,which can be welding to the tank or install in the tank by tri-clamp .which all fit GMPs and FDA ,

Manhole is a safety emergency ventilation device installed on the top of the storage tank. It is usually used together with fire extinguisher and mechanical breather valve. It can not only avoid accidents caused by sudden overpressure or vacuum in the tank and damage the tank, but also play a role of safety and fire resistance. It is a safety device to protect the storage tank, especially suitable for the dome roof atmospheric pressure tank with materials sealed with nitrogen. The utility model has the advantages of constant pressure discharge, constant pressure suction, flexible opening and closing, safe fire resistance, compact structure, good sealing performance, safety and reliability, etc
Manholes are generally made of 304 and 316L stainless steel plates.

cleaning ball is made of AISI304 or AISI316L, which is applied to the effective cleaning of storage tanks for dairy products, beer, food, beverage, pharmaceutical, etc.
structure of CIP spray ball:
Connection: screw type, clamp type (quick installation), pin type, welding type;
Structure: nozzle type tank washing machine, rotary cleaning ball, fixed cleaning ball (spray cleaning ball);
Finish: internal surface mechanical polishing RA ≤ 0.4-0.8 μ m,
Technical Datas

Availably standard	SMS,DIN,3A,IDF,RJT, BS, ISO
Material Quality	SS304, SS316L
Availabe Connection	Welding ends,triclamp ends,union ends,male ends
Seal Material	Silicone, EPDM,NBR
Glass	Heavy Wall Borosilicate (Pyrex) Tubing; Polycarbonate (Lexan) Tubing; Acrylic Tubing; etc
Protection Lens Cover	Polycarbonate Tubing,Acrylic Tubing or Slotted Stainless Steel
Screw Blot	Full Stainless Steel
Structure	Straight way,cross
Pressure range	0bar~10bar
Machine Processing	The most advanced CNC machine from Japan for processing
Continuous working temperature	20°C ~ +135°C (EPDM,Silicone)
Special Design	we can produce according to your drawings
