• Model NO.：HY Fittings
• Transport Package：Carton
• Specification：ISO, CE
• Trademark：HYRUBBERS
• Origin：Shandong, China
• HS Code：73079900
• Production Capacity：100000 PCS Within a Month



  HOSE BORE
DIMENSIONS
  PART NO.
THREAD E
DN
DASH
C
S
H
22691-02-03
G1/8"X28
4
03
5.5
14
31.5
22691-04-04
G1/4"X19
6
04
5.5
19
36.5
22691-06-06
G3/8"X19
10
06
6.3
22
43
22691-08-08
G1/2"X14
12
08
7.5
27
51
22691-10-10
G5/8"X14
16
10
9.5
30
56
22691-12-12
G3/4"X14
20
12
10.9
32
66
22691-16-16
G1"X11
25
16
11.7
41
73.8
22691-20-20
G1.1/4"X11
32
20
11
50
87
22691-24-24
G1.1/4"X11
38
24
13
55
102
22691-32-32
G2"X11
51
32
16
70
125.3

Note: 1.For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is 22692-xx-xx.

Competitive Advantage1) We are professional manufacturer with 11 years' experience, enjoy good reputation oversea
 2) Full range of advanced equipment ,testing line ensure production capacity and satisfactory quality
 3) Top quality with competitive price and fast delivery bring us very good reputation all over the world .
 4) Our Hose includes such features as constant working pressures, low expansion, low temperature
 and high temperature applications

============================================================================
