• Trademark：GMS
• Origin：China
• HS Code：8307100000

Pipe Diameter

DN1/2-32inch (DN12-800mm)

Pipe Material

SS321, 304, 316, 316L

Pipe Type

Annular corrugated pipe

Pipe thickness

0.28-1.0mm

Braided mesh material

SS304

Braided mesh layer

single layer or double layers or three layer

Max. woking pressure

10Mpa~35MPa

Working temperature

(-200)~(+800) °c

Connect type

Flange, nuts, fast fittings,

Standard

GB/T14525-2010, ANSI,JIS,DIN,GOST

Flange material

stainless steel or carbon steel

Pipe assembly length

according to clients' requirements

Our main products include:

• stainless steel flexible metal hose, expansion joint. Bellow, convoluted tube and stainless steel braided nets.

Note Tips:

•  Our company offer customized services for different requirement, whenever you have an inquiry, please let me know your related parameters such as:

1. the materials. ( SS304, 321, 316, 316L etc.)
2.  the end connections. (such as flange, screw nuts, fast fittings etc)
3. the out  & inner diameter,
4. the length & the pressure,
5. the application.

• and we will very appreciate if you could offer the drawing/blueprints / pictures for us taking a reference.
• any idea or question, feel free to contact with us.

Production process


1 Steel plate rolling : the steel plate will be thin and we cut them for limited width

2 Rolled round and automatic welding:steel plated rolled to steel pipe,and automatic welding the chink

3 Bellows forming:hydraulic system and mould,it can be pressed out the bellows

4 braided reinforcement:steel wire braided,but usually we have the hose nuts,and we put the metal bellows into the hose nuts.

5 welding:welding the nuts and the hose,welding the hose and the joints

6 pressure test:it must be test,and we can ensure the cooling metal hose 100% no leakage.

Company Introduction

Wuxi City Ge Ming Sheng Steel Trading Co.,Ltd (China Metal Hose Factory)

Who located in China(Wuxi)Rubber and plastic pipe base and founded in 2012, 50 employees, the professional and senior technicians are 100 totally. We have advanced standards for design, mainly produce stainless steel metal hoses, metal bellows, nets, metal&non-metallic compensator polyurethane, high/low pressure hose, hose sheathed insulation, all kind of connectors and other products. Which are widely used in electric power, dock, construction, steel, mining, petroleum, chemical, cement, transportation and other industries of various pipes and equipment.

All the products have passed the ISO9001 international quality system certification.
