NPT Male Hydraulic Hose Parker One-Piece Pipe Fitting Chinese Factory
Ningbo Yinzhou Shuntong Hydraulic Equipment Co., Ltd.- Standard：DIN, GB
- Material：Medium Carbon Steel
- Connection：Male
- Surface Treatment：Chrome
- Head Type：Hexagon
- Size：1,4"-2"
Base Info
- Model NO.：15611P-B
- Thread：NPT,Bsp,Jic,BSPT
- Type：One-Piece Fitting Intergal Fitting
- Color：Yellow White
- Transport Package：Pallet
- Specification：15611P-B
- Trademark：ST
- Origin：Ningbo, China
- HS Code：7307990000
- Production Capacity：100000PCS,Year
Description
DIMENSIONSPART NO. THREAD E DN DASH A C S1 15611P-04-04B ZG1/4"X19 6 04 27 15 17 15611P-06-04B ZG3/8"X19 6 04 28 16 19 15611P-06-06B ZG3/8"X19 10 06 27.5 16 19 15611P-08-06B ZG1/2"X14 10 06 33 19.5 22 15611P-08-08B ZG1/2"X14 12 08 33 19.5 22 15611P-08-10B ZG1/2"X14 16 10 34.5 19.5 22 15611P-12-08B ZG3/4"X14 12 08 35 19.5 27 15611P-12-10B ZG3/4"X14 16 10 36.5 19.5 27 15611P-12-12B ZG3/4"X14 20 12 35.5 19.5 27 15611P-16-12B ZG1"X11 20 12 42.5 25.5 36 15611P-16-16B ZG1"X11 25 16 45.7 25.5 36 15611P-20-20B ZG1.1/4"X11 32 20 48.7 26.5 46 15611P-24-24B ZG1.1/2X11 40 24 52.5 27.5 50 15611P-32-32B ZG2"X11 50 32 58 27.5 65
FAQ
1. What accessories are needed for mining service?
Hydraulic hose assembly, hose fittings, hydraulic adapters,couplings...Including ferrules, flanges, fittings of BSP, JIC,NPT,METRIC,ORFS,BSPT,SAE, JIS...Contact us directly, will reply you in quick time.
2. How long it will take from guangzhou to your factory?
About 4 hours by Plane.
3. Where is your factory located?
Our factory is in Ningbo.
4. Do you have any real pictures of the product?
Sure,You can leave your any contact information and I will share the picture with you.
FAQ1. What accessories are needed for mining service?
Hydraulic hose assembly, hose fittings, hydraulic adapters,couplings...Including ferrules, flanges, fittings of BSP, JIC,NPT,METRIC,ORFS,BSPT,SAE, JIS...Contact us directly, will reply you in quick time.
2. How long it will take from guangzhou to your factory?
About 4 hours by Plane.
3. Where is your factory located?
Our factory is in Ningbo.
4. Do you have any real pictures of the product?
Sure,You can leave your any contact information and I will share the picture with you.
