Hardware Fasteners Long Domed Head Countersunk Head Blind Rivet
Guangdong Chunqing Hardware Electronics Co., Ltd.- Certification：ISO, GS, RoHS, CE
- Performance：Eco-Friendly
- Customized：Customized
- Available Material：Automotive Industry, Food & Beverage, General Indu
- Transport Package：Original Packing,According to Your Requirement
- Specification：3,32′(2.0),1,8′(3.2),5,32′(4.0),3,16′(4.8),1,4′(6)
Base Info
- Model NO.：BLIND RIVETS
- Trademark：CQ
- Origin：Dongguan China
- HS Code：7318151090
- Production Capacity：1000000piece,Month
Description
Blind Rivet Specificaiton
Rivet Series Number
Nominal Rivet Size
(D) Body Diameter
(W) Mandrel Diameter
Dome Head
Large Flange
Countersunk Head
Max.
Min.
(A) Head Dia.
(H) Max Head Hgt.
(A) Head Dia.
(H) Max Head Hgt.
(A) Head Dia.
(H) Max Head Hgt.
1
3/32 (2.4mm)
0.096
0.09
0.057
0.187
0.032
0.281
0.04
0.18
0.028
2
1/8
0.128
0.122
0.076
0.25
0.04
0.375
0.065
0.226
0.032
(3.2mm)
3
5/32
0.159
0.153
0.095
0.312
0.05
0.469
0.075
0.281
0.04
(4.0mm)
4
3/16
0.191
0.183
0.114
0.375
0.06
0.625
0.092
0.344
0.05
(4.8mm)
5
1/4
0.255
0.246
0.151
0.5
0.08
0.75
0.107
0.468
0.071
(6.4mm)
Normal Size or Basic Shank Diameter
D
A
H
Shank Diameter
Head Diameter
Head Height
Max
Min
Max
Min
Max
Min
0.062(1/16)
0.064
0.059
0.14
0.12
0.027
0.017
0.094(3/32)
0.096
0.09
0.2
0.18
0.038
0.026
0.125(1/8)
0.158
0.152
0.323
0.301
0.059
0.045
0.188(3/16)
0.191
0.182
0.387
0.361
0.069
0.055
0.219(7/32)
0.222
0.213
0.453
0.427
0.08
0.065
0.25(1/4)
0.253
0.244
0.515
0.485
0.091
0.075
0.281(9/32)
0.285
0.273
0.579
0.545
0.103
0.085
0.312(5/16)
0.316
0.304
0.641
0.607
0.113
0.095
0.344(11/32)
0.348
0.336
0.705
0.667
0.124
0.104
0.3759(3/8)
0.38
0.365
0.769
0.731
0.135
0.115
0.406(13/32)
0.411
0.396
0.834
0.79
0.146
0.124
0.438(7/16)
0.443
0.428
0.896
0.852
0.157
0.135
How to order?
Please provide the product you need parameters:
1. You need the product name
2. You need the amount of products
3. You need the material of products
4. You need the product specifications
Because it is convenient we can more quickly to give you a quotation. Thanks!
