• Model NO.：EZS
• Manufacturing Way：Press
• Size：1,2"-72"
• Materials：CS,Ss,Alloy
• Sch：10,40,80,160,Std,Xh,Xxh,etc
• Types：Weld-Neck
• Face：FF,RF etc
• Delivery Time：7-15days
• Shipment：Container or Bulk Vessel
• Package：Wooden Case or Other Requirment
• Transport Package：Wooden Case
• Specification：#150
• Trademark：EZS
• Origin：Tianjin China
• HS Code：7307210000
• Production Capacity：20000ton,Year

Basic Info.

Model NO. EZS Manufacturing Way Press Size 1/2"-72" Materials CS,Ss,Alloy Sch 10,40,80,160,Std,Xh,Xxh,etc Types Weld-Neck Face FF,RF etc Delivery Time 7-15days Shipment Container or Bulk Vessel Package Wooden Case or Other Requirment Transport Package Wooden Case Specification #150 Trademark EZS Origin Tianjin China HS Code 7307210000 Production Capacity 20000ton/Year

Product Description

Carbon Steel Pipe flange, 310S Wn DN200 Flange(API Steel Tube Fitting)
We provide ANSI, API, and AWWA pipe flanges in carbon steel, stainless steel, alloys, and chrome steel. Styles we offer include Weld Neck, Slip On, Blind, Threaded, Socket Weld, Lap Joint, Orifice Flanges, Ring, and custom flanges in sizes from 1/2″ to 203″. Pressure classes we offer include 75, 125, 150, 175, 250, 300, 350, 400, 600, 900, 1500, 2500, 5K, 10K, 15K, 20K. High Yield - Low Temp.

Material:

• CARBON STEEL - ASTM/ASME SA-105, A-350 LF-2, LF-3, A694, SA-516-70, A36
• CHROME ALLOYS - A-182-F-1, F-5, F-6, F-9, F-91, F-11, F-12, F-22
• STAINLESS STEEL - A-182 - F-304, Dual Grade 304/304L, Dual Grade 316/316L, 316, 304H, Dual Grade 304/304H, Dual Grade 316/316H, 316H, 309,
• 310, 317L, 321, 347, 347H, 904L,
• Alloy 20, many other H grades
• ALUMINUM - 3003, 6061, 5083 and other grades upon request.
• HASTALLOY - B-2, C-276, G, X, C-22
• INCONEL - 600, 601, 625, 718
• INCOLLOY - 800, 825, 800H, 800HT
• MONEL - 400
• COPPER - 90/10 (C70600), 70/30 (C71500)
• Duplex - F51/2205, F53/2507
• TITANIUM - Gr2, Gr12





WELD NECK FLANGE

Our most frequently requested flange, the Weld Neck Flange features a neck extension and weld bevel. Provides a natural form connection ideal for larger, high-pressure applications.



SLIP ON FLANGE

A simple alternative to the Weld Neck flange, a Slip On Flange is designed to accept the pipe into the center/bore, allowing welding around the outer diameter of the pipe.



BLIND FLANGE

Designed to cap off a line, a Blind Flange has no bore or inner diameter. They are often altered to include NPT threads or custom bore holes to function as hubless Slip On flanges.




SOCKET WELD / COUNTER BORE FLANGE

Sometimes referred to as Counter Bore flanges, the Socket Weld types have a socket to insert pipe when space limitations make Weld Neck flanges difficult to use.



THREADED / COMPANION FLANGE

Threaded or Companion Flanges contain a female NPT threaded center for connection to male threaded piping. These flanges are commonly implemented in reducing connections.




LAP JOINT FLANGE

Lap Joint Flanges are intended to saddle over a stub end fitting. They feature an extended hub and a machined radius at the base of the flat face.
